The YewdaleDefiant® C47 electric cassetted blind with side channels features a Yewdale motor as standard. The cassette is designed for top or face fixing and accommodates a 40mm grooved aluminium barrel, housing the 230v AC Yewdale motor. The motor is controlled by a switch/transformer which may be surface or flush mounted. The fabric is locked into a groove in the barrel with studs fitted at the edge of the fabric to retain it within the side channels. Aluminium Tear Drop bottom bar. Black or white hardware as standard.


The C47 offers a premium electric operated cassetted blind for situations where durability and functionality are required. It’s quiet and reliable motor is housed within the barrel and further protected by the robust aluminium head-box housing. The fabric is locked into barrel and bottom bar and will give years of trouble-free use. It is located in the groove in such a way that, although it cannot be pulled out it may be slid out sideways for easy repair or replacement of blind cover.


Black or white hardware; Without side channels, C27-90/120; Remote and/or group control systems in place of single switch; Tracker fabric retaining system; Available in any RAL colour.


YewdaleDefiant® C47-90/120 electric cassetted blind with side channels as manufactured by Yewdale. Flame retardant fabric from the YewdaleDefiant® range, locked into grooved 53/70mm aluminium barrel along with aluminium bottom bar as standard. 230v AC Yewdale motor is housed within black/white aluminium cassette with side channels and bottom bar.

CodeDescriptionCassette size (HxD)Barrel size ØSide channel size (WxD)Min Width
Electric 230v105 x 95mm
140 x 120mm
55x 13mm
55x 13mm

Based on fabric weight of 400g/m², e.g. Dart. Larger sizes may be possible with lighter/thinner fabrics. Sizes shown in millimetres unless otherwise specified.

SKU: C47-90 Categories: ,
